VERTICAL LAMINAR FLOW HOOD SIZE 2x2 , MODEL WITH UV LIGHT, PRE FILTER INSTALLED
VERTICAL LAMINAR FLOW HOOD SIZE 2x2 , MODEL WITH UV LIGHT, PRE FILTER INSTALLED
Regular price
Rs.60,000.00 PKR
Regular price
Sale price
Rs.60,000.00 PKR
Unit price
/
per
Couldn't load pickup availability
Description
Vertical Laminar Flow Hood / Cabinet (also called clean bench) provides sample protection as purified air travels across the working zone of the cabinet in a vertical, unidirectional stream and leaves the main work chamber across the entire open front of the cabinet.
Most vertical Laminar Flow Hood also has perforations at the back wall of the work zone which are designed to eliminate air turbulence and the possibility of dead air corners in the work zone.
Applications
- Microbiology (non-pathogenic)
- Forensics
- Sterile product compounding
Advantages
Humanized Features:
- Ergonomic Control Panel Location, centered and angled down for easy reach & viewing
- The brushed stainless steel work surface is for easy cleaning
- The non-direct light source design can effectively relieve the operator’s visual fatigue under the condition of ensuring the illumination
- Intuitive and easy-to-use microprocessor controller with LCD display, graphical and digital display of the operating status of each function, such as filter life, UV life, etc.
Safety Features
- Front sliding sash interlock with fan and UV lamp
- UV sterilization with UV lamp timing function
- The front sash and side windows are made of UV-resistant tempered glass
- The host and sockets have independent capacitors to prevent current overload
Convenience Features
- Memory function in case of power failure
- HEPA filter and UV life indicators facilitate a timely replacement plan
- Two side glass windows were installed for easy experiment observation
- Easy-to-change pre-filter installed could extend the HEPA filter’s lifetime
- Equipped with a temperature sensor to show the real temperature during operation
- Waterproof sockets provide convenience for small instruments to be used in the operating area
Specifications
LCB-VF Series Vertical Laminar Flow Hood | ||||
Model | LCB-V3F | LCB-V4F | LCB-V5F | LCB-V6F |
External Dimensions(W*D*H)(mm) | 1050*708*1850 | 1320*708*1850 | 1625*708*1850 | 1930*708*1850 |
Internal Dimensions(W*D*H)(mm) | 950*615*625 | 1220*615*625 | 1525*615*625 | 1830*615*625 |
Control System | Microprocessor controller with LCD display, graphical and digital display of the operating status of each function. | |||
Work Surface Height | 750mm | |||
Airflow Velocity | Adjustable, 0.2~0.5 m/s | |||
HEPA Filter Efficiency | > 99.995% at particle size of 0.3 μm | |||
Pre-Filter | 1 pc., made of washable polyester fiber | |||
Sound Emission | ≤62dB(A) | |||
Fluorescent Lamp | LED Type, Intensity ≥900Lx | |||
UV Lamp | With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. | |||
Power Consumption | 155W | 285W | 285W | 300W |
Doesn’t include external device connected via power socket | ||||
Cabinet Construction | Main Body: Electro-galvanized steel with antimicrobial Powder Coating | |||
Work Zone: Stainless steel, grade 304 | ||||
Manual Sliding Sash: 5 mm UV Resistant Tempered Glass with counter-balance system and ergonomic handle | ||||
Side Windows: 5 mm UV Resistant tempered glass | ||||
Electricity | AC220V ±10%, 50/60Hz,1P | |||
Standard Accessories | Base stand; LED lamp; UV lamp; Waterproof socket*2 (only 1 for LCB-V3F) | |||
Optional Accessories | Water Tap, Gas Tap, IV bar, Height adjustable base stand | |||
Shipping Weight(kg) | 225 | 255 | 285 | 330 |
Shipping Dimensions(L*W*H)(mm) | 1190*990*1325 | 1460*990*1325 | 1765*990*1325 | 2070*990*1325 |
Shipping Volume (m3) | 1.56 | 1.92 | 2.3 | 2.7 |
